Hardline Strip & Core Tool Kit for QR540 Cable (HSC-540QR)

Ships direct from the manufacturer. Please allow up to 10 business days, though it often ships sooner.

QR540 is a Quantum Reach cable, and its .540 in (13.72 mm) outer conductor and dielectric don't match a .500 tool; a coring bit sized for 500-series hardline either won't enter or cores it oversize. The Jonard Tools HSC-540QR Hardline Strip and Core Tool is sized for QR540 specifically, for the day a QR540 cable has to be terminated, replaced, or given a new connector. Built-in ratcheting handles make the coring faster and easier on the wrist, the heavy-duty aluminum body is built to last a lifetime, and the blades and coring bit are replaceable, so the tool never has to be replaced as a whole; the replacement coring bit is the HCB-540QR. At 1.72 lb it's the heaviest tool in the hardline kit and the only one that fits this cable.

Features

• Made for QR540 Quantum Reach cable. Specifically designed for the .540 in (13.72 mm) size.
• Terminate, replace, or add a connector. For the connector work a QR540 plant calls for.
• Built-in ratcheting handles. Comfort and speed through the core.
• Heavy-duty aluminum body. Built to last a lifetime.
• Replaceable blades and coring bits. Sold separately, so there's never a reason to replace the whole tool; the replacement coring bit is the HCB-540QR.

Where It Fits

It suits CATV and broadband line technicians on a QR540 plant fitting connectors at taps, splices, and amplifiers, construction crews building or extending QR540 distribution, maintenance techs replacing a damaged connector or a section of cable on an existing QR540 run, contractors who meet QR540 on one system and .500 on the next and need a tool for each, anyone who has tried to core QR540 with a .500 tool and found out why it doesn't work, and a truck that carries the HSC-50 for 500-series and needs its QR540 counterpart. For .500 cable, the HSC-50 cores and strips, the HC-50 cores with four preset lengths, and the HS-50 strips; the JIC-750 banana cutter makes the square cut any of them start from, and the CC-120 cleans the center conductor after the core.

Good to Know

Check the cable marking before the tool goes on: QR540 is .540 in over the outer conductor, and this tool is sized for that and not for .500 (P3, T10) or .625, which have their own tools, so a cable that doesn't enter the bit cleanly is the wrong cable, not a dull bit. Start with a square cut end from a banana cutter; a crushed or angled end won't start in the coring bit. Insert the cable, work the ratcheting handles in a steady motion without forcing them, and let the bit do the coring; pushing hard loads the center conductor and is what scores it. After the prep, inspect the center conductor for a smooth finish and no scoring, the outer conductor for burrs, and the core for dielectric left behind, which keeps the connector from seating and shows up later as an intermittent; a center conductor cleaner takes off the film the coring leaves. Confirm the finished dimensions against the QR540 connector's instructions, since connector makers differ. Change the blades when the cut starts to tear and the coring bit (HCB-540QR) when the core comes out rough. Hardline on a CATV plant carries AC power to amplifiers; confirm the line is dead before cutting or coring.
