CAT8 RJ45 Keystone Jack – Shielded 40G Tool-Less, 180° High Density

CAT8 RJ45 Keystone Jack – Shielded 40G

Our CAT8 Shielded HD Component-Rated line represents our premier data jack solution for high-performance 40 Gigabit networks. These shielded CAT8 keystone jacks feature advanced PCB technology, phosphor bronze IDC contacts, gold-plated prongs, and zinc die-cast housing with nickel plating for superior EMI and alien crosstalk protection. The tool-less design with IDC cap simplifies termination with easy-to-read wire labels, universal T568A/T568B wiring, and optional tool-less installation. Compatible with both solid and stranded 22-24 AWG wire, these jacks help you save time and money. Supports PoE++ (802.3bt) 4PPoE up to 100W and is fully backward compatible with Category 6A.

We take great pride in our quality control procedures and commitment to excellence. Our CAT8 Shielded HD Component-Rated keystone jacks are UL Listed and meet all requirements for ANSI/EIA/TIA 568.2-D compliance. They are rigorously inspected and tested to comply with stringent industry transmission and safety standards.

Key Features

• CAT8 performance supporting 40G speeds up to 2 GHz
• Component-rated for superior performance and reliability
• Fully backward compatible with Category 6A
• Shielded zinc die-cast housing with nickel plating protects against EMI and alien crosstalk
• High-density slim profile for space-efficient installations
• PoE++ (802.3bt) 4PPoE support up to 100W
• Gold-plated nickel contacts provide corrosion resistance and optimal signal conductivity
• Phosphor bronze IDC contacts for excellent conductivity and wear resistance
• 8-pin × 8-conductor configuration for streamlined connection
• 180° rear-facing design reduces termination time
• Easy-to-read wiring label with integrated T568A/T568B diagram
• Tool-less termination option when using IDC cap
• Innovative jack design keeps pairs together to streamline installation
• Compatible with solid and stranded 22-24 AWG wire
• Durable construction: 750+ mating cycles minimum
• Meets and exceeds ANSI/TIA 568.2-D standards
• UL Compliant

Technical Specifications

• Performance: CAT8, 40G up to 2 GHz
• Configuration: 8-pin × 8-conductor
• Wire Compatibility: Solid and stranded 22-24 AWG
• Housing Material: Zinc die-cast with nickel plating
• Contact Bracket: PC, UL 94-V2, transparent
• RJ45 Contact Material: Phosphor bronze with nickel plating
• Contact Finish: 50 micro-inch gold plating
• Cap A&B: Zinc die-cast with nickel plating
• IDC Housing: PC + glass fiber, gray, UL 94V-2
• Terminal: Phosphor bronze with tin plating
• IDC Cap: PC + glass fiber, UL94-HB, white
• PCB: UL 94V-0
• Insertion Force: 30N maximum
• Retention Strength: 7.7 kg between jack and plug
• Operating Temperature Range: -10°C to 60°C (14°F to 140°F)
• Mating Cycles: 750 cycles minimum
• Power Support: PoE++ (802.3bt) up to 100W
• Standards Compliance: ISO/IEC 11801, ANSI/TIA 568.2-D
• Certifications: UL Compliant
• Termination: 180° rear-facing, optional tool-less with IDC cap
