22/2 Riser Rated Alarm Cable - CMR/CL3R, Shielded, Stranded Copper, 1000ft
Couldn't load pickup availability
22/2 AWG Riser Security Alarm Bulk Cable - CMR/CL3R Rated, Shielded, 1000ft
This professional-grade 22 AWG 2-conductor riser security alarm bulk cable is engineered for reliable performance in vertical runs between floors in residential and commercial buildings. Featuring aluminum foil shielding and stranded bare copper conductors, this CMR-rated cable meets strict fire safety standards for riser applications while protecting against electromagnetic interference.
Proudly made in the USA, this versatile shielded cable is ideal for security systems, intercoms, audio distribution, and power-limited control circuits in electrically noisy environments. With sequential footage marking for accurate tracking and supplied in a convenient 1,000 ft pull-box, this cable provides interference protection for demanding installations. ETL listed and RoHS compliant for quality assurance and code compliance.
Key Features
- Riser rated (CMR/CL3R) for installation in vertical shafts between floors
- Aluminum foil shielding protects against EMI/RFI interference in noisy environments
- 22 AWG 2-conductor configuration perfect for basic security zones with interference protection
- 7-strand bare copper conductors provide flexibility during installation
- Sequential footage marking printed on jacket for accurate measuring and tracking
- Gray PVC jacket low-smoke construction for code compliance
- ETL listed and RoHS compliant for safety and quality assurance
- Made in USA for consistent quality and reliability
- FT4 fire test rated meets stringent fire safety requirements
- Pull-box packaging 1,000 ft for convenient, tangle-free dispensing
- Code compliant meets NEC requirements for riser installations
- Versatile applications suitable for security, intercom, and audio systems in high-interference areas
Ideal Applications
- Security and burglar alarm systems in noisy environments
- Intercom and communication systems near electrical equipment
- Sound and audio distribution in high-interference areas
- Access control systems
- Power-limited control circuits requiring shielding
- Multi-floor residential and commercial installations
- Vertical runs near electrical panels or power equipment
- Installations in industrial or manufacturing facilities
- Any basic alarm circuit requiring two conductors with EMI protection
Technical Specifications
Cable Type & Performance
- Category: Security alarm cable
- Gauge: 22 AWG (2 conductors)
- Construction: Stranded (7 strands per conductor)
- Shielding: Aluminum foil shield for EMI/RFI protection
- Voltage Rating: 300V
- Temperature Rating: 75°C
Physical Construction
- Conductor Material: Bare copper, stranded
- Strand Count: 7 strands per conductor
- Individual Conductor Diameter: 1.2mm
- Conductor Insulation: PVC
- Shield: Aluminum foil
- Outer Jacket Material: Low smoke PVC, gray
- Jacket Thickness: 0.38mm
- Nominal Overall Diameter: 3.30mm
- Sequential Footage Marking: Yes, printed on jacket
- Conductor Resistance: 21.20 Ω/km
Conductor Color Code
- Red
- Black
Fire & Safety Ratings
- Jacket Rating: CMR (Communications Riser)
- CL3R Rating: Class 3 Riser for power-limited circuits
- Fire Test: FT4 rated for enhanced fire safety
- NEC Articles: 725 (CL2R/CL3R), 760 (FPLR), 800 (CMR)
Packaging
- Length: 1,000 feet
- Package Type: Pull-box for tangle-free dispensing
- Country of Origin: Made in USA
Compliance & Certification
- ETL Listed
- RoHS Compliant
- NEC compliant for riser installations
- Meets building code requirements for vertical runs
Installation Notes
This 22/2 riser security alarm bulk cable is specifically designed for vertical installations between floors in non-plenum spaces, such as riser shafts, elevator shafts, and vertical cable runs in walls. The CMR/CL3R rating ensures the cable meets fire safety requirements for these applications.
CMR/CL3R Riser Rating: The dual CMR/CL3R rating indicates:
- CMR (Communications Riser): Suitable for vertical runs per NEC Article 800
- CL3R (Class 3 Riser): Suitable for power-limited circuits per NEC Article 725
- FT4 Fire Test: Enhanced fire safety performance
- Meets fire safety standards for riser applications
- NOT suitable for plenum spaces (use CMP-rated cable)
- Appropriate for vertical cable runs between floors
Aluminum Foil Shielding: The aluminum foil shield provides important benefits:
- EMI/RFI protection: Blocks electromagnetic and radio frequency interference
- Signal integrity: Maintains clean signal transmission in noisy environments
- Prevents crosstalk: Reduces interference from adjacent cables
- Suitable for high-interference areas: Near electrical equipment, fluorescent lighting, motors
When to Choose Shielded: Choose this shielded cable when:
- Installation is near electrical panels, motors, or power equipment
- Environment has fluorescent lighting or electronic equipment
- Industrial or manufacturing facility with machinery
- Signal integrity is critical and interference is a concern
- Building codes or specifications require shielding
22 AWG Gauge: The 22 AWG size offers:
- Excellent flexibility for security alarm applications
- Adequate current-carrying capacity for most alarm circuits
- Easy termination at control panels and devices
- Good performance for moderate-length runs
Sequential Footage Marking: The printed footage markers on the jacket allow you to:
- Track cable usage and remaining length in the pull-box
- Calculate exact lengths needed for vertical runs
- Maintain accurate installation documentation
- Avoid waste and ensure adequate supply
Made in USA: USA manufacturing ensures:
- Consistent quality control
- Compliance with domestic standards
- Support for American manufacturing
- Reliable supply chain
Low Smoke PVC Jacket: The low-smoke gray PVC jacket provides:
- Reduced smoke generation in fire situations
- Code-compliant construction
- Professional gray appearance
- Durability for long-term installations
22/2 Shielded Configuration Applications: The 2-conductor shielded design is perfect for:
- Basic security alarm zones with interference protection
- Door and window contacts in noisy environments
- Motion detector connections near electrical equipment
- Simple intercom systems requiring EMI protection
- Basic audio distribution in high-interference areas
- Any two-wire application requiring shielding
This professional-grade USA-made riser security alarm bulk cable provides reliable, code-compliant performance with interference protection for vertical installations in residential and commercial buildings where EMI/RFI shielding is required for optimal system performance.
