CAT6A Slim Shielded Ethernet Patch Cable - U/FTP

CAT6A Ultra-Slim Shielded Ethernet Patch Cable - Snagless, U/FTP, 10 Gbps

This ultra-slim Cat6A U/FTP shielded patch cable delivers full 10 Gigabit Ethernet performance with maximum EMI/RFI protection in a compact 4.8mm diameter form factor. Featuring individual foil shielding on each twisted pair, this cable combines the space-saving benefits of slim design with superior interference protection for demanding high-density environments. Perfect for installations requiring both minimal cable bulk and shielded performance.

Ideal for high-density data centers, server racks, industrial facilities, PoE++ installations, and any environment where space constraints meet electromagnetic interference challenges. Available in multiple lengths and colors for organized cable management.

Key Features

• Ultra-slim 4.8mm profile compact diameter keeps high-density panels organized and cool
• U/FTP shielding individual foil shielding per twisted pair minimizes EMI/RFI for reliable signals
• Full 10GBase-T performance certified for 10 Gbps at 100 meters with complete Cat6A specifications
• 500 MHz bandwidth maintains superior performance despite slim profile
• 28 AWG stranded copper conductors provide flexibility for easy routing and long-term durability
• Snagless molded boot protects RJ-45 clips during installation and frequent moves
• Enhanced airflow management slim shielded design improves cooling in dense installations
• PoE++ compatible supports high-power applications with interference protection
• UL listed and ETL verified professional-grade quality and safety assurance
• RoHS compliant environmentally responsible manufacturing
• Gold-plated contacts ensure corrosion resistance and consistent performance
• Multiple lengths available for optimized cable management
• Color-coded options for easy network organization and identification

Ideal Applications

• High-density data center rack installations with EMI concerns
• Industrial environments requiring interference protection
• Server racks near power equipment or electrical panels
• PoE++ powered devices in electrically noisy environments
• Medical facilities requiring shielded connections
• Audio/video production environments
• Manufacturing floors with heavy machinery
• Top-of-rack switches in high-interference areas
• Dense patch panels requiring both space savings and shielding
• Network closets with limited space and EMI sources
• Environments combining space constraints with electrical noise
• Any installation requiring slim profile + interference protection

Technical Specifications

Cable Type & Performance

• Category: Cat6A (Category 6 Augmented)

• Shielding Type: U/FTP (Unshielded overall/Foiled Twisted Pair)

  • Individual foil shielding per twisted pair
  • No overall shield (maintains flexibility)

• Data Rate: 10GBase-T (10 Gbps at full 100 meters)

• Speed Support: 10/100/1000 Mbps Ethernet, 2.5GBase-T, 5GBase-T, 10GBase-T

• Bandwidth: Up to 500 MHz

• Wiring Standard: T568B

• EMI/RFI Protection: Individual foil per pair

Physical Construction

• Conductor Material: Bare copper, stranded
• Conductor Gauge: 28 AWG (ultra-slim)
• Outer Jacket Material: PVC, flexible (Indoor rated)
• Outer Diameter: 4.8 ± 0.3 mm (slim shielded design)
• Boot Type: Snagless molded design with latch protection

Connectors

• Connector Type: RJ-45 (8P8C) male, shielded, on both ends
• Contact Plating: Gold-plated for corrosion resistance
• Boot Protection: Snagless molded latch cover
• Connector Shielding: Fully shielded metal housing

Power over Ethernet

• PoE Support: IEEE 802.3bt (PoE++)
• Power Delivery: Supports PoE++ applications with shielding protection

Available Options

• Multiple lengths available
• Multiple color options for cable organization

Compliance & Rating

• Indoor rated (PVC jacket)
• RoHS compliant
• UL listed
• ETL verified
• ANSI/TIA standards compliant

Installation Notes

This Cat6A ultra-slim shielded patch cable represents a unique solution that combines two critical advantages: the space-saving benefits of slim 28 AWG construction with the interference protection of U/FTP shielding. This makes it ideal for environments where both cable bulk reduction and EMI/RFI protection are essential.

U/FTP Shielding Design: The U/FTP (Unshielded overall/Foiled Twisted Pair) construction features individual foil shielding around each of the four twisted pairs, but no overall shield surrounding the entire cable assembly. This design provides:

• Excellent protection against external electromagnetic interference
• Superior flexibility compared to overall-shielded designs
• Reduced cable diameter compared to S/FTP or F/FTP constructions
• Effective crosstalk suppression in high-density installations

Slim Profile with Shielding: At 4.8mm diameter, this cable is significantly thinner than standard Cat6A shielded cables while maintaining full 10 Gigabit performance and interference protection. This provides critical advantages:

• Reduced cable bundle size in high-density installations
• Improved airflow through densely packed server racks
• Easier routing in tight spaces and cable management systems
• Better cooling efficiency in enclosed racks and cabinets

Full Cat6A Performance: Despite the ultra-slim construction, this cable maintains complete Cat6A specifications:

• 10 Gbps at 100 meters: Full-distance 10GBase-T performance
• 500 MHz bandwidth: Complete Cat6A specification
• PoE++ support: Handles high-power applications with heat dissipation
• ANSI/TIA compliant: Meets industry standards

When to Choose This Cable: This slim shielded Cat6A cable is the ideal choice when you need:

• Space savings in high-density installations
• EMI/RFI protection from nearby power equipment, motors, or electrical panels
• Full-distance 10 Gigabit Ethernet performance
• PoE++ support in electrically noisy environments
• Maximum port density with interference protection

Shielding Comparison:

• U/FTP (this cable): Foil per pair, no overall shield. Best balance of protection, flexibility, and slim profile
• S/FTP: Foil per pair + overall braid. Maximum protection but bulkier and less flexible
• F/UTP: Overall foil only. Good protection but less effective than per-pair shielding
• UTP: No shielding. Slimmest and most flexible but no EMI protection

Important Grounding Considerations: For optimal shielding effectiveness:

• Ensure both connected devices have shielded RJ-45 ports
• Use shielded patch panels and keystones throughout the installation
• Maintain proper grounding and bonding practices
• The shielding must have a continuous ground path from end to end

28 AWG Performance Notes: While 28 AWG slim cables offer excellent performance for most applications, they have slightly higher resistance than thicker cables. This shielded slim Cat6A cable is ideal for:

• Typical data center patch applications with EMI concerns
• High-density rack installations near power equipment
• Short to medium runs requiring interference protection

The combination of slim profile, shielding, and full Cat6A performance makes this cable a premium solution for modern data centers and industrial environments where space efficiency and interference protection must coexist.

• C6ASLSS Data Sheet
